veneer roller dryer manufacturers

1.Professional factory production

2.Customizable (customized one-stop service)

3.The roller uses a φ89mm special shaft tube, which is corrosion-resistant and rust-proof

4.Stable equipment and low failure rate

5.The veneer is flat and wrinkle-free after drying

6.The main electrical components are all well-known domestic and foreign brands


  Contact Now
Product Details

Shine 2 deck veneer dryer is cost-effective and uses a new axial fan to reduce the power of the whole machine, saving energy and electricity for you. The veneer drying process consists of two parts: blowing heating by the blowing pipe and contact heating by the upper and lower pressing rollers. Double heating improves the heating efficiency. It can be matched with different heat sources (biomass burner, thermal oil and natural gas, etc.), and while producing efficiently, it ensures that the dried boards are good, flat and wrinkle-free. We welcome you to visit the case site.


veneer drying.jpg


Advantages of veneer drying


1、The hot air fan and cold air fan of the dryer adopt the latest axial flow fan, which reduces power consumption and greatly reduces the power of the whole machine, which can further reduce the later operation cost.

2、The Shine heat exchanger adopts step-by-step heat exchange. The specifications of each heat exchanger are different, and the hot air inside can be evenly distributed to the single board. After drying, the moisture content of the veneer is uniform, smooth, without wrinkles or end ripples, without cracks, and the surface is in good glued state.

3、The roller veneer dryer adopts frequency conversion speed regulation, which can adjust the feeding speed according to your veneer thickness and moisture content, so as to achieve the ideal drying effect.

4、The fuel source can be waste wood or bark after peeling, which can greatly reduce fuel costs for users.

5、Perfect after-sales service system, 24-hour online service, remote operation, so that customers can rest assured after installation. Regular follow-up services for old customers, sufficient and timely supply of spare parts.


veneer drying.jpg


Product Parameters of veneer drying


Wood species

Veneer Drying capacity (m³/h)

Veneer water moisture

Veneer thickness and size


1 deck veneer dryer

2 deck veneer dryer

4 deck veneer dryer

6 deck veneer dryer



Eucalyptus

0.5-2

1-3.3

2-9.0

15-17

Fresh Veneers (above 70%) to about 0-10%

0.8-8mm

Birch

0.6-2.2

1.2-3.8

2.3-10

15-18

Fresh Veneers (above 70%) to about 0-10%

0.8-8mm

Rubberwood

0.6-2.2

1.2-3.8

2.3-10

15-18

Fresh Veneers (above 60%) to about 0%

0.8-8mm

Poplar

0.6-2.2

1.2-3.8

2.3-10

15-18

Fresh Veneers (above 50%) to about 0-10%

0.8-8mm

Beech

0.6-2.2

1.2-3.8

2.3-10

15-18

Fresh Veneers (above 70%) to about 0-10%

0.8-8mm

Pine

0.6-2.2

1.2-3.8

2.3-10

15-18

Fresh Veneers (above 70%) to about 0-10%

0.8-8mm

Other

0.6-2.2

1.2-3.8

2.3-10

15-18

Fresh Veneers (above 70%) to about 0-10%

0.8-8mm

shine veneer dryer can dry various types of wood. If you want to know more detailed information, please feel free to contact us!
