plywood jet roller veneer dryer
1.Customizable (customized one-stop service)
2.The roller uses a φ89mm special shaft tube, which is corrosion-resistant and rust-proof
3.Highly automated and efficient (fully automatic veneer feeding and receiving system)
4.Stable equipment and low failure rate
5.Has been exported to Europe, South America, Asia, Africa and other regions, and can be viewed in real time
6.Automatic grading technology improves production efficiency and product consistency
The veneer drying process consists of two parts: heating by blowing pipe and contact heating by upper and lower pressing rollers. Double heating improves heating efficiency. Both the hot air blower and the cold air blower of the veneer dryer adopt the new axial flow fan, which not only fully guarantees the air volume required for drying, but also reduces the total installed power by more than 38%, and minimizes the power consumption of the whole set of equipment. Diversified heat sources are available. Our dryers can be equipped with a variety of heat sources, including steam boilers, thermal oil boilers, natural gas, burners, steam generators, etc.
Advantages of Roller Veneer Dryer
1. The well-developed heat exchange system fully improves the energy utilization rate and saves unnecessary energy waste.
2. The control cabinet has automatic temperature control and speed regulation system, which can accurately control the final moisture content. Simple operation and low failure rate.
3. The temperature in the burner is 40-60 ℃ higher than that of the traditional dryer (steam, thermal oil), and the temperature is controlled at 140-180 ℃, which shortens the drying time and increases the output.
4. After drying, the veneer is smooth, with no cracks, wrinkles, or end ripples.
5. Shrinkage and hardening are kept to a minimum and veneer collapse and honeycomb structure are avoided.
6. We have a professional R&D team which can design different models according to customer’s special requirement.
7. The perfect after-sale service team can supply 24 hours online service.
Product Parameters of Roller Veneer Dryer
Wood species | Veneer Drying capacity (m³/h) | Veneer water moisture | Veneer thickness and size | |||
1 deck veneer dryer | 2 deck veneer dryer | 4 deck veneer dryer | 6 deck veneer dryer | |||
Eucalyptus | 0.5-2 | 1-3.3 | 2-9.0 | 15-17 | Fresh Veneers (above 70%) to about 0-10% | 0.8-8mm |
Birch | 0.6-2.2 | 1.2-3.8 | 2.3-10 | 15-18 | Fresh Veneers (above 70%) to about 0-10% | 0.8-8mm |
Rubberwood | 0.6-2.2 | 1.2-3.8 | 2.3-10 | 15-18 | Fresh Veneers (above 60%) to about 0% | 0.8-8mm |
Poplar | 0.6-2.2 | 1.2-3.8 | 2.3-10 | 15-18 | Fresh Veneers (above 50%) to about 0-10% | 0.8-8mm |
Beech | 0.6-2.2 | 1.2-3.8 | 2.3-10 | 15-18 | Fresh Veneers (above 70%) to about 0-10% | 0.8-8mm |
Pine | 0.6-2.2 | 1.2-3.8 | 2.3-10 | 15-18 | Fresh Veneers (above 70%) to about 0-10% | 0.8-8mm |
Other | 0.6-2.2 | 1.2-3.8 | 2.3-10 | 15-18 | Fresh Veneers (above 70%) to about 0-10% | 0.8-8mm |
shine veneer dryer can dry various types of wood. If you want to know more detailed information, please feel free to contact us! | ||||||
Customer Case
Exhibition
The Factory
Packaging & Shipping
